Product Features

  • Beams over 4’ have 3 spreads. Outside spread, Outside less 1’, Outside less 2’.
  • 3’ & 4’ beams have 2 spreads.
  • Swivel hooks with hook latches standard.
  • Standard capacities to 40 tons, larger capacities and configurations available.
  • Complies with ASME standards.

Product Options

  • OPTION A: Extra Holes or Different Placement of Holes – Allows multiple hook positioning beyond standard 3 spreads. Specify number and spread(s) required.
  • OPTION B: Faspins – For ease of positioning hooks with quick release. Specify number required.
  • OPTION C: Extra Hooks – Allows for multiple pick points. Specify number required.
  • OPTION D: Pin Type Bail – Lifting pin located between structural channel. (Hoist hook information must be supplied.)
  • OPTION E: Shackle Lug – Lifting lug with shackle (Headroom may change.)

Product Specifications


Model 20 Specifications
Dimensions in inches, unless noted.
Model numbers shown in red are part of our QUICKSHIP program.
Model Number Capacity (tons) Spread (ft) A (in.) B (in.) C (in.) T (in.) O (in.) HR (in.) Weight (lbs)
20-1/2-3 1/2 3 7/8 3 5 3/4 7/8 12-3/4 40
20-1/2-4 1/2 4 7/8 3 5 3/4 7/8 12-3/4 50
20-1/2-6 1/2 6 7/8 3 5 3/4 7/8 12-3/4 65
20-1/2-8 1/2 8 7/8 3 5 3/4 7/8 12-3/4 95
20-1/2-10 1/2 10 7/8 3 5 3/4 7/8 13-3/4 140
20-1/2-12 1/2 12 7/8 3 5 3/4 7/8 13-3/4 160
20-1/2-14 1/2 14 7/8 3 5 3/4 7/8 14-3/4 230
20-1/2-16 1/2 16 7/8 3 5 3/4 7/8 15-3/4 305
20-1/2-18 1/2 18 7/8 3 5 3/4 7/8 16-3/4 400
20-1/2-20 1/2 20 7/8 3 5 3/4 7/8 16-3/4 450
20-1/2-24 1/2 24 7/8 3 5 3/4 7/8 20-1/4 830
20-1/2-30 1/2 30 7/8 3 5 3/4 7/8 22-1/4 1340
20-1-3 1 3 7/8 3 5 3/4 7/8 12-3/4 40
20-1-4 1 4 7/8 3 5 3/4 7/8 12-3/4 50
20-1-6 1 6 7/8 3 5 3/4 7/8 13-3/4 85
20-1-8 1 8 7/8 3 5 3/4 7/8 12-3/4 115
20-1-10 1 10 7/8 3 5 3/4 7/8 14-3/4 165
20-1-12 1 12 7/8 3 5 3/4 7/8 15-3/4 230
20-1-14 1 14 7/8 3 5 3/4 7/8 16-3/4 320
20-1-16 1 16 7/8 3 5 3/4 7/8 18-1/2 415
20-1-18 1 18 7/8 3 5 3/4 7/8 20-1/4 605
20-1-20 1 20 7/8 3 5 3/4 7/8 20-1/4 675
20-1-24 1 24 7/8 3 5 3/4 7/8 22-1/4 1095
20-2-3 2 3 7/8 3 5 3/4 7/8 13-3/4 50
20-2-4 2 4 7/8 3 5 3/4 7/8 13-3/4 65
20-2-6 2 6 7/8 3 5 3/4 7/8 13-3/4 100
20-2-8 2 8 7/8 3 5 3/4 7/8 16-1/2 165
20-2-10 2 10 7/8 3 5 3/4 7/8 17-1/2 230
20-2-12 2 12 7/8 3 5 3/4 7/8 18-1/4 315
20-2-14 2 14 7/8 3 5 3/4 7/8 20-1/4 480
20-2-16 2 16 7/8 3 5 3/4 7/8 20-1/4 540
20-2-18 2 18 7/8 3 5 3/4 7/8 24-3/4 800
20-2-20 2 20 7/8 3 5 3/4 7/8 24-3/4 900
20-2-24 2 24 7/8 3 5 3/4 /78 27-3/4 1730
20-3-3 3 3 1-1/4 3 5 1 1 15-1/4 70
20-3-4 3 4 1-1/4 3 5 1 1 15-1/4 80
20-3-6 3 6 1-1/4 3 5 1 1 16-1/4 140
20-3-8 3 8 1-1/4 3 5 1 1 17-1/4 200
20-3-10 3 10 1-1/4 3 5 1 1 18-1/4 275
20-3-12 3 12 1-1/4 3 5 1 1 22-1/2 415
20-3-14 3 14 1-1/4 3 5 1 1 24-1/2 650
20-3-16 3 16 1-1/4 3 5 1 1 24-1/2 1295
20-3-18 3 18 1-1/4 3 5 1 1 27-1/2 1295
20-3-20 3 20 1-1/4 3 5 1 1 27-1/2 1450
20-3-24 3 24 1-1/4 3 5 1 1 27-1/2 1765
20-5-3 5 3 2 4 7 1-1/4 1-15/16 19-1/2 115
20-5-4 5 4 2 4 7 1-1/4 1-15/16 20-1/2 145
20-5-6 5 6 2 4 7 1-1/4 1-15/16 21-1/2 205
20-5-8 5 8 2 4 7 1-1/4 1-15/16 25-1/2 325
20-5-10 5 10 2 4 7 1-1/4 1-15/16 25-1/2 390
20-5-12 5 12 2 4 7 1-1/4 1-15/16 27-1/2 580
20-5-14 5 14 2 4 7 1-1/4 1-15/16 27-1/2 690
20-5-16 5 16 2 4 7 1-1/4 1-15/16 30-1/4 1210
20-5-18 5 18 2 4 7 1-1/4 1-15/16 30-1/4 1340
20-5-20 5 20 2 4 7 1-1/4 1-15/16 30-1/4 1505
20-5-24 5 24 2 4 7 1-1/4 1-15/15 33-1/4 2275
20-7 1/2-3 7-1/2 3 2 4 7 1-1/4 1-1/2 22-1/2 135
20-7 1/2-4 7-1/2 4 2 4 7 1-1/4 1-1/2 23-1/2 170
20-7 1/2-6 7-1/2 6 2 4 7 1-1/4 1-1/2 25-1/4 265
20-7 1/2-8 7-1/2 8 2 4 7 1-1/4 1-1/2 27-1/4 415
20-7 1/2-10 7-1/2 10 2 4 7 1-1/4 1-1/2 27-1/4 500
20-7 1/2-12 7-1/2 12 2 4 7 1-1/4 1-1/2 30-1/4 910
20-7 1/2-14 7-1/2 14 2 4 7 1-1/4 1-1/2 30-1/4 1070
20-7 1/2-16 7-1/2 16 2 4 7 1-1/4 1-1/2 30-1/4 1210
20-7 1/2-18 7-1/2 18 2 4 7 1-1/4 1-1/2 33 1665
20-10-3 10 3 2 4 7 1-1/4 1- 9/16 23-1/4 150
20-10-4 10 4 2 4 7 1-1/4 1-9/16 25-1/4 205
20-10-8 10 8 2 4 7 1-1/4 1-9/16 27-1/4 420
20-10-6 10 6 2 4 7 1-1/4 1-9/16 27-1/4 335
20-10-10 10 10 2 4 7 1-1/4 1-9/16 30-1/4 775
20-10-12 10 12 2 4 7 1-1/4 1-9/16 30-1/4 910
20-10-14 10 14 2 4 7 1-1/4 1-9/16 30-1/4 1075
20-10-16 10 16 2 4 7 1-1/4 1-9/16 33 1500
20-10-18 10 18 2 4 7 1-1/4 1-9/16 33 1670
20-15-3 15 3 2-1/2 5 9 1-1/2 2-1/16 28-1/2 215
20-15-4 15 4 2-1/2 5 9 1-1/2 2-1/16 25-1/4 295
20-15-6 15 6 2-1/2 5 9 1-1/2 2-1/16 30-1/2 375
20-15-8 15 8 2-1/2 5 9 1-1/2 2-1/16 33-1/2 685
20-15-10 15 10 2-1/2 5 9 1-1/2 2-1/16 33-1/2 820
20-15-12 15 12 2-1/2 5 9 1-1/2 2-1/16 40-1/4 1180
20-15-14 15 14 2-1/2 5 9 1-1/2 2-1/16 40-1/4 1385
20-20-3 20 3 2-1/2 5 9 1-1/2 2-1/4 38-3/4 370
20-20-4 20 4 2-1/2 5 9 1-1/2 2-1/4 38-3/4 435
20-20-6 20 6 2-1/2 5 9 1-1/2 2-1/4 38-3/4 575
20-20-8 20 8 2-1/2 5 9 1-1/2 2-1/4 38-3/4 710
20-20-10 20 10 2-1/2 5 9 1-1/2 2-1/4 41-1/2 1070
20-20-12 20 12 2-1/2 5 9 1-1/2 2-1/4 41-1/2 1235
20-25-4 25 4 3 6 12 1-1/2 2-1/4 41-3/8 470
20-25-6 25 6 3 6 12 1-3/4 2-1/4 41-3/8 590
20-25-8 25 8 3 6 12 1-3/4 2-1/4 44-3/8 925
20-25-10 25 10 3 6 12 1-3/4 2-1/4 44-3/8 1100
20-25-12 25 12 3 6 12 1-3/4 2-1/4 44-3/8 1650
20-30-4 30 4 3-1/2 7 16 2 2-1/4 45-1/2 525
20-30-6 30 6 3-1/2 7 16 2 2-1/4 45-1/2 660
20-30-8 30 8 3-1/2 7 16 2 2-1/4 48-1/4 1010
20-40-4 40 4 3-1/2 7 16 2-1/2 3 44-3/4 600
20-40-6 40 6 3-1/2 7 16 2-1/2 3 47-3/4 930
